Torque Wrenches Vs Tensioners

Post by: Admin

Torque wrenches and bolt tensioners are among the most common way of tightening large bolts.

In most cases, bolts wind up under more stress and need to provide more clamping force as the equipment grows more powerful or heavier. When dealing with larger bolts, hydraulic wrenches or tensioners are necessary to tighten bolts to a point that they’ve created sufficient clamping force.

Bolts can provide support to the objects they are clamping; their main purpose is to deliver clamping force. This force comes from the spring tension intrinsic to the tightened bolt. As the bolt is tightened, it undergoes a microscopic stretching. But the bolt’s original make-up includes an elasticity of material that leads it to want to revert to its shape before this stretching occurred. This tension leads to the clamping force, and works to prevent loosening with the help of the friction from the bolt’s threads.

Therefore, guaranteeing and maintaining proper clamping force will ensure that enough spring tension is created in a bolt upon tightening. Torque wrenches and bolt tensioners each create this spring tension by stretching bolts, although they use different methods to get to that goal.

Bolt Tensioners

A bolt tensioner preloads a bolt and stretches it before a nut is installed. The tensioner gets held to the threads of the bolt and pushes against the flange of the surface that is being bolted. By doing this, the tensioner provides a steady amount of stretch to the bolt, thus making sure the bolt receives consistent stretch and clamping force.

There is a downside to using bolt tensioners, in that the user needs to consider a number of factors in selecting a tensioner with each application. This Includes;

Bolts can provide support to the objects they are clamping; their main purpose is to deliver clamping force. This force comes from the spring tension intrinsic to the tightened bolt. As the bolt is tightened, it undergoes a microscopic stretching. But the bolt’s original make-up includes an elasticity of material that leads it to want to revert to its shape before this stretching occurred. This tension leads to the clamping force, and works to prevent loosening with the help of the friction from the bolt’s threads.

  • The size of the nut
  • The diameter of the bolt
  • The thickness of the washer
  • The washer diameter
  • The bolt grade and load requirement
  • The free stud protrusion length

With a tensioner, the amount of bolt stretch is regulated by the hydraulic pressure applied to the tool. Because the bolt will be pre-stretched by the tensioner, the user will need a minimal amount of torque to tighten the nut on the stud. The clamping pressure needed comes from the release of the tensioner, which allows the bolt’s innate elasticity to supply clamping pressure

Torque Wrenches

A torque wrench generates spring tension through the amount of rotational force it applies to a bolt. As the wrench applies this force, the threading pulls the nut face and bolt head close, stretching the bolt and generating clamping force. It’s the most commonly found method of supplying load to a bolt. A large amount of torque is necessary to provide high clamping force. A hydraulic wrench can supply this kind of force.

Torque in hydraulic wrenches is controlled by hydraulic fluid pressure; the higher the pressure, the greater the amount of torque applied to the bolt. Hydraulic fluid does not compress, which means it provides highly consistent and precise torque values.

For the highest potential accuracy when determining torque for a specific application, it is vital to consider a number of other factors that can affect the amount of clamping force applied by a particular level of torque. This includes,

  • The number of times the bolt has been used
  • The bolt’s cleanliness and finish
  • Whether a lubricant has been applied to the threads and the nut face
  • Whether flat washers have been used
21
Aug

Hydrotest Pumps Supplier

Post by: Admin

Hydratron manufactures a comprehensive range of Hand operated and Air Driven Liquid Pumps capable of developing pressures in excess of 45,000psi (3100bar). Their compact size, minimal weight and ability to operate in many environments gives them a broad appeal in a wide range of duties, including mobile, fixed and offshore installations.

Gulf Incon International is the largest supplier of Hydrotest pumps, Gas booster pumps and hydraulic flushing rigs in Dubai, UAE. We are supplying Hydratron’s High pressure equipments. Hydratron is a Global leader in the manufacture of High Pressure Air Driven Liquid Pumps, Gas Boosters and associated Systems.

The Hydratron range of Standard Hydraulic Power Units (HPU) provides customers looking for pre-engineered and user friendly Liquid Pump systems. These incorporated our full range of Air Driven, Hand Powered and Electric/Petrol driven pump solutions. They are designed for ease of use and to provide for simple connectivity to the inlet and outlet ports. Additional instrumentation can be installed if required including Stroke Counters, Chart Recorders and Pressure Transducers. On-board tanks can also be integrated if required.

Different series of Liquid pumps are there.

AZ-1 Series

An Air operated liquid pump for pressure testing, chemical injection and hydraulic power

Double Acting Series

A Double Acting positive displacement pump with a directly coupled, integral linear reciprocating air motor

Double Head Double Acting Series

A Double air Head Double Acting reciprocating, positive displacement pump

Hand Pump Series

A Hand Powered spring-return positive displacement pump designed to generate High Static Liquid Pressures.

For more info please checkout our site and do a call our highly trained staffs will give you a full picture about hydrostatic pumps and get a quote.
